1RE Open Body Radial Piston Pump For Upto 350Bar Pressure and 10.1LPM
Speed Range : 300 to 2000 RPM
Temperature Range : -20C to +80C
Viscosity Range : 10cSt to 100cSt
Model Details:-
1RE 5C
Number of pumping Elements : 5
Connection : Delivery Port- 3/8″ Female
Max Pressure : 350 Bar
Geometric Displacement : 4.5cm3
Flow : 6.2LPM
1RE 3D
Number of pumping Elements : 3
Connection : Suction Port- 1/2″ Female | Delivery Port- 3/8″ Female
Max Pressure : 300 Bar
Geometric Displacement : 3.18cm3
Flow : 4.3LPM
1RE 5D
Number of pumping Elements : 5
Connection : Suction Port- 1/2″ Female | Delivery Port- 3/8″ Female
Max Pressure : 300 Bar
Geometric Displacement : 5.3cm3
Flow : 7.2LPM
1RE 7C
Number of pumping Elements : 5
Connection : Suction Port- 1/2″ Female | Delivery Port- 3/8″ Female
Max Pressure : 350 Bar
Geometric Displacement : 6.3cm3
Flow : 8.6LPM
1RE 7D
Number of pumping Elements : 5
Connection : Suction Port- 1/2″ Female | Delivery Port- 3/8″ Female
Max Pressure : 300 Bar
Geometric Displacement : 7.42cm3
Flow : 10.1LPM
Price range: ₹5,100 through ₹8,925 Exclusive GST
Model 1R**** are small, low weight, rugged oil immersed type Radial
Piston Pump with 2, 3, 5 or 7 pumping elements. These pumps are
valve controlled and have no restriction on direction of rotation.
Pumps with model 1RE*** have extension shaft for through drive and
are available with extension bracket assembly for coupling a low
pressure pump having standard flange as per ISO 3019/1.
These are available with 28 displacements and 7 pressure ratings.
These pumps give fixed output per revolution of the shaft.
For information on different models of radial piston pump, Please visit here.
