Water Level Indicator
Function:
To indicate the level of water in the boiler continuously, also known as a water gauge. A bronze water level gauge for steam systems ensures accurate monitoring and safe boiler operation.
Description:
Normally, two water level indicators are fitted at the front end of every boiler. When the boiler drum is positioned at a height, the gauge is often inclined for better visibility from different angles. As water converts into steam during operation, the level inside the boiler decreases. Maintaining a safe water level is critical—if it drops below the safe limit, serious damage such as cracks or leakage may occur, leading to shutdown of steam generation.
A Bronze Water Level Gauge Set Screwed type is widely used due to its durability, corrosion resistance, and suitability for high-temperature steam applications. If you are planning to buy bronze water level gauge, it is important to choose a reliable and high-quality set to ensure safety and performance.
Working:
The system uses cocks to control the passage of steam and water. When opened, the water level in the glass tube matches the boiler water level, allowing easy monitoring. A drain cock is provided to periodically remove accumulated sediments and maintain accuracy.
The upper and lower stuffing boxes are connected by a hollow metal column. Under normal conditions, safety balls remain in position. In case the glass tube breaks due to pressure, these balls automatically move to shut off steam and water flow, ensuring operator safety. The cocks can then be closed safely, and the damaged glass tube replaced.
Additionally, screwed caps are provided for internal cleaning after dismantling. The design is robust and prevents splintering, ensuring that even if the glass breaks, it does not harm the operator.
Very sturdy and well-finished gauge set. The valve operation is smooth, and the gauge glass seals perfectly without leakage. The bronze body has excellent corrosion resistance. Works efficiently for continuous service conditions.
Excellent product for boiler applications! The construction is strong, and both the screwed and flange ends are machined precisely. The isolation valves work effortlessly, and the gauge gives clear water level indication.
Very well-designed gauge set — compact, efficient, and durable. The glass fittings are secure, and the valve operation is smooth. Fully compliant with IBR standards. Ideal for industrial boiler monitoring.
This Bronze Water Level Gauge Set (Screwed / Flange End) is truly reliable and well-engineered. The glass tube and valve assembly are robust, and visibility is crystal clear even under steam pressure. Perfect alignment and easy to maintain.
Good-quality water level gauge with clear visibility. The assembly comes with proper seating, and the valves are easy to operate. Bronze construction ensures rust-free performance and long life.
