Cast Steel (WCB) IBR Certified Safety Valve Pop Type Flange End Class 150#
, ,

Cast Steel (WCB) IBR Certified Safety Valve Pop Type Flange End Class 150#

(5 customer reviews)

IBR Certified
Each valve comes with individual IBR certificate
Brand: Aira
Body MOC: WCB
Working parts: CF8M
Pressure: 0.5 to 6Kg/cm2
Temperature: Upto 350C
Seals: Metal to Metal
Media: Water/Steam/Oil

Price range: ₹14,846 through ₹27,600 Exclusive GST

The principle type of device used to prevent overpressure in plant is the safety or safety relief valve. The safety valve operates by releasing a volume of fluid from within the plant when a predetermined maximum pressure is reached, thereby reducing the excess pressure in a safe manner. As the safety valve may be the only remaining device to prevent catastrophic failure under overpressure conditions, it is important that any such device is capable of operating at all times and under all possible conditions.
Safety valves should be installed wherever the maximum allowable working pressure (MAWP) of a system or pressure-containing vessel is likely to be exceeded. In steam systems, safety valves are typically used for boiler overpressure protection and other applications such as downstream of pressure reducing controls. Although their primary role is for safety, safety valves are also used in process operations to prevent product damage due to excess pressure. Pressure excess can be generated in a number of different situations, including:

  • An imbalance of fluid flowrate caused by inadvertently closed or opened isolation valves on a process vessel.
  • Failure of a cooling system, which allows vapour or fluid to expand.
  • Compressed air or electrical power failure to control instrumentation.
  • Transient pressure surges.
  • Exposure to plant fires.
  • Heat exchanger tube failure.
  • Uncontrollable exothermic reactions in chemical plants.
  • Ambient temperature changes.

FAQs – Cast Steel (WCB) IBR Certified Safety Valve Pop Type Flange End Class 150#:

1. What is the main function of a Cast Steel (WCB) IBR Certified Safety Valve Pop Type Flange?
A Cast Steel (WCB) IBR Certified Safety Valve Pop Type Flange is designed to protect pressurized systems by releasing excess pressure quickly, preventing damage to boilers, pipelines, and equipment.

2. Is the Safety Valve Pop Type Flange suitable for high-pressure steam or liquid applications?
Yes, the Safety Valve Pop Type Flange is IBR certified and engineered for high-pressure steam and liquid systems in industrial and process applications.

3. How does the pop-type mechanism of the Safety Valve Pop Type Flange improve safety?
The pop-type mechanism ensures rapid and complete opening at set pressure, allowing for immediate pressure relief and reliable system protection.

4. Can the flange end design of the Safety Valve Pop Type Flange simplify installation?
Yes, the flange end design allows secure, leak-proof mounting on pipelines, making installation easier and maintenance more convenient.

5. What maintenance is required for a Cast Steel Safety Valve Pop Type Flange?
Regular inspection and cleaning of the Safety Valve Pop Type Flange are recommended to maintain precise operation, ensure proper pressure settings, and extend service life.
